SPECIFICATIONS :
|
Power Voltage |
220V/50 Hz/1 Ph/1.1 Kw
380V/60 Hz/3 Ph/0.75 Kw |
|
WorkingAir Pressure |
0.7-0.8 MPa |
| Rim Diameter
|
11’’-22’’ |
|
Rim Width |
4” – 15” (100 – 380 mm) |
|
Max. Wheel |
41" (1050 mm) |
|
Average Rotate speed |
6.8 rpm |
|
Shovel force |
2000 Kg. |
|
Gross/Net Weight |
350/270 Kg. |
|
Packing dimension |
1150 x 1000 x 960 mm |
|
|
Features
|
|
|
|
Beryllium copper air inflation indicator cassette mechanism, durable and accurate.
|
|
|
|
Foot Valve adopts stainless steel valve rod. |
