TECHNICAL DATA:
|
Lamps (Pcs)
|
3 Nos
|
|
Input Power Supply
|
Single Phase 230 V,60 Hz
|
|
Rated Input Current (A)
|
15
|
|
Input Power (W)
|
3300
|
|
Baking Square (mm)
|
1200 x 1000
|
|
Working Distance (m)
|
0.5-0.7
|
|
Max. Baking Height (mm)
|
1.9
|
|
Power Cable Length (m)
|
5
|
|
Total Lamp Length (mm)
|
531
|
|
Heating Length (mm)
|
446
|
|
Lamp Diameter (mm)
|
20
|
|
Average Lamp Life
|
5000 Hours
|
|
Cable Connection
|
Tab
|
|
Time Set up
|
0 min – 60 min, variable regulation
|
|
Light Intensity
|
10%-100%
|
|
|
Features
|
|
|
|
Made from aluminium alloy, bright stainless steel and other special materials |
|
|
|
Equipped with V power 21' quartz short wave infrared light tubes |
|
|
|
Full automatic device equipped with LCD digital electric timer |
|
|
|
Front and back regulate. Up and down movement, can acheive roof of auto |
|
|
|
Single phase 220V 15A 50Hz 3*1100W |
|
|
|
Baking square: 1200*1000mm |
|
|
|
Temperature: 40-75degree |
|
|
|
Set time: 0min-60min Variable regulation |
